For wide outdoor work areas that need a truss gantry with two trolley positions and a segmented structure that can be transported through restricted site access.

Henan Mine Crane meh double-trolley truss gantry crane showing the primary gantry structure and lifting arrangement.
The MEH double-trolley truss gantry crane is a rail-mounted general gantry crane. The source lists working class A3–A5, optional cantilever arrangements and variable-frequency control for lifting and travel.
A key source feature is segmented construction: main girders and end structures can be transported through narrow areas and assembled by bolts on site. For a buyer, the double-trolley operating logic must be defined separately—maximum load per trolley, whether both are used together, lifting-point spacing and any synchronization requirement.
| Product Model | MEH |
| Type-Test Product Name | General Gantry Crane |
| Lifting Capacity | Source-stated where published; otherwise project-specific |
| Span | Source-stated where published; otherwise project-specific |
| Lifting Height | Project-specific unless source-stated |
| Runway / Travel Length | Project-specific |
| Working Duty | Source-stated where published; otherwise selected from actual duty |
| Lifting Attachment | According to the product and load |
| Control Method | Source-supported options + project requirements |
| Operating Environment | According to actual site conditions |
Request A MEH Double-Trolley Truss Gantry Crane Quote
Product title identifies a double-trolley truss gantry crane.
Source working class A3–A5.
Optional cantilever on both sides, one side or no cantilever.
Any capacity, span, speed, synchronization accuracy, wind limit, temperature limit, throughput or other contractual value that is not explicitly published by the source should be engineered from the actual project and written into the technical agreement.
Two trolley positions can be engineered around separate or combined lifting tasks.
Useful where long crane structures cannot be delivered to site in one piece.
Provides a defined duty family for general outdoor operation.
Supports smoother movement and positioning.
Source explicitly supports wide coverage and adjustable lifting-height design.
Official source image associated with the truss gantry crane structure or application. |
Official source image associated with the truss gantry crane structure or application. |
| Gantry Structure | Main girder(s), legs and end structures selected from the exact product layout, load, span and site conditions. |
| Hoisting / Trolley System | Configured around the product's source-described lifting mechanism and operating cycle. |
| Lifting Attachment | Hook, grab, magnet, gantry hook, gate lifting device or construction attachment according to the product. |
| Gantry Travel System | Moves the crane along the fixed ground rail or semi-gantry runway. |
| Electrical & Control System | Configured from source-supported controls and project-specific safety / automation requirements. |
| Model | MEH |
| Product Type | MEH Double-Trolley Truss Gantry Crane |
| Type-Test Product Name | General Gantry Crane |
| Capacity | Project-specific unless source-stated |
| Span | Project-specific unless source-stated |
| Lifting Height | Project-specific unless source-stated |
| Runway Length | Project-specific |
| Hoisting Speed | Project-specific |
| Trolley Travel Speed | Project-specific |
| Gantry Travel Speed | Project-specific |
| Working Duty | Project-specific unless source-stated |
| Control Method | Project-specific |
| Power Supply | According to site electrical conditions |
| Site Environment | According to wind, rain, dust, corrosion and temperature |
Source-confirmed product facts:
Buyer-defined items:
| Large Yards | Wide-area material handling. |
| Restricted-Access Sites | Projects requiring segmented delivery and site assembly. |
| Long-Load Handling | Two lifting points where the project requires them. |
| Equipment Installation | Flexible lift height and trolley layout. |
Provide each trolley's independent maximum load.
If both trolleys lift together, provide center of gravity and lifting-point spacing.
State any allowable hook-height difference; the source does not publish one universal value.
Provide maximum module length / width / weight allowed to reach the site.
Truss geometry still requires project wind and rail / foundation data.
| Per-Trolley Load | Do not assume equal load sharing. |
| Combined Lift | Define whether both trolleys are ever used together. |
| Synchronization | Project-specific; source does not publish a numerical tolerance. |
| Transport Modules | Provide site access limits for segmented delivery. |
Before manufacture, confirm rail center distance, runway length, rail elevation, foundation or building-runway capacity, available lifting height, process clearances, power supply and erection access. Outdoor projects should include wind, rain, temperature, corrosion and anchoring conditions.
Maintenance should follow the final supplied crane manual and actual duty. In addition to hoisting, brakes, ropes, wheels, drives, rails, limits and electrical systems, inspect product-specific devices such as grabs, magnets, gantry hooks, gate equipment, tipping mechanisms, encoders, cameras or automation hardware.
| 1 | Total maximum load |
| 2 | Maximum load per trolley |
| 3 | Load dimensions / center of gravity |
| 4 | Lifting-point spacing |
| 5 | Synchronization requirement if applicable |
| 6 | Span |
| 7 | Lifting height |
| 8 | Runway length |
| 9 | Transport access restrictions |
| 10 | A3–A5 duty inputs |
| 11 | Cantilever requirement |
| 12 | Wind / foundation / destination |
Use the complete suspended load, including the load plus grab, magnet, gantry hook, lifting beam, rigging or any other below-the-hook equipment.
Yes. Unless the source publishes a range, these are project-specific and should be selected from the rail layout and working envelope.
Send a plan and cross-section showing rails, foundations or building runway, loading positions, obstacles, travel length and available clearances.
Where the source supports VFD, PLC, linked operation, cameras, access control or other functions, the final scope should be defined from the buyer's process and acceptance requirements.
Treat them as source product data. If a value is contract-critical for a new project, define the test conditions and acceptance method in the technical agreement.
Send your maximum load, span, lifting height, runway length, site drawing, operating cycle, load geometry, lifting attachment and special control / environment requirements. Henan Mine Crane engineers can then review the actual process and prepare a project-specific configuration and quotation.
